Features of magnetic flip-flop level gauge with alarm and remote transmission

Project Overview

1. Features of remote transmission and alarm magnetic flap level gauges:

1. Simple structure, easy installation, novel instructions, intuitive and eye-catching readings, and users can change their observations according to their own requirements Angle;

2. The measurement range is large and is not limited by the height of the storage tank. The indicating mechanism is completely isolated from the measured medium, so it has good sealing, high numerical reliability, and high safety factor;

3. It can integrate on-site instructions and control panel;

4. It can withstand high temperatures and can use non-fading ceramic turning columns.

2. Magnetic switch selection instructions:

1. Point-through model: This product consists of a stainless steel shell switch and a clamp, which is installed on the outside of the stainless steel pipe. When inside the steel pipe When the magnetic float moves past it as the liquid level rises and falls, the magnetic switch changes from the normally open state (OFF) to the conductive state (ON).

Technical parameters:

Applicable voltage: ≤250V

Maximum switching current: ≤1A

Load: ≤DC30W/AC30W

Ambient temperature: ≤100℃

Outline dimensions (mm): length 65×width 25×height 313cm

Cable length (m): 2

2. Holding type

This product consists of a stainless steel shell switch and a clamp, which is installed on the outside of the stainless steel pipe. When the magnetic float in the steel pipe passes through it as the liquid level rises and falls, the magnetic switch That is, it changes from the normally open state (OFF) to the conductive state (ON) and maintains this state. The opposite is true for the reverse installation state.

Technical parameters:

Applicable voltage: ≤250V

3. Product technical parameters:

Measurement accuracy: ±1 cm

Measuring range (L): 0~6000 Medium density: ≥0.45 g/cm3

Media density: ≥0.45 g/cm3

Working temperature: -20 ℃ -400 ℃

Working pressure: 1.0 1.6 2.5 4.0 6.3 10.0 MPa

Connecting flange size: DN20 DN25 DN40 DN50

IV. Description

The flange connection holes are square by default. If the distribution is not square, please specify the matching flange when ordering.

When placing the float, the heavy end (magnetic end) of the float faces upward.

If the liquid level gauge exceeds 4 meters, a flange or pipe clamp needs to be added for reinforcement.
