Installation form has an impact on the flow range of metal tube rotameters

Project Overview

1. Influence Mechanism

The flow range of the metal tube rotor flowmeter is not only affected by its diameter, but also by the installation form. Different installation forms (such as vertical installation and horizontal installation) will cause the flow state of the fluid in the flow meter to change, thus affecting the measurement range and accuracy of the flow meter.

2. Specific impact

1. Vertical installation:

• Small flow range: In vertical installation, in order to avoid the influence of gravity, the fluid flow direction must be full pipe from bottom to top. This type of installation may limit the flow range of the flow meter because the fluid needs to overcome the force of gravity to pass through the flow meter.

• Accuracy considerations: When installing vertically, it is necessary to ensure that the verticality of the flow meter is better than a certain standard (such as 1%) to ensure measurement accuracy.



2. Horizontal installation:

• Large flow range: In horizontal installation, the fluid flow direction is not limited by gravity and can be left in and right out or right in and left out, so the flow range is relatively large.

• High flexibility: Horizontal installation provides more flexibility in the layout of the flow meter and can adapt to different pipeline layouts and installation conditions.



3. Other influencing factors

In addition to the installation form, the flow range of the metal tube rotor flowmeter is also affected by the following factors:

1. Float material: Floats of different materials (such as stainless steel, PTFE, titanium, etc.) have different physical properties and measurement ranges. For example, stainless steel floats can usually measure a wider range, but may be accompanied by greater pressure loss and accuracy effects.

2. Float size: Under the same caliber, the larger the float size, the larger the flow range. However, an excessively large float size may increase the pressure loss of the instrument, thereby affecting the measurement accuracy.

3. Pipeline conditions: The length, diameter, straight pipe length of the upstream and downstream pipelines, and the fluid state in the pipeline (such as temperature, pressure, flow rate, etc.) will all affect the measurement range and accuracy of the flow meter.

IV. Conclusion

In summary, the installation form has a significant impact on the flow range of the metal tube rotor flowmeter. When selecting and installing a metal tube rotor flowmeter, it is necessary to select the appropriate installation form and flowmeter parameters according to the specific measurement requirements and pipeline conditions to ensure the accuracy and reliability of measurement. At the same time, you also need to pay attention to following the relevant installation specifications and standards during the installation process to ensure the flow meter'sNormal operation and long-term use effects.
